Body assembly process - engine compartment checking fixture

検具・検査治具.comでの検具・検査治具の実績事例として、車体組立工程のエンジンコンパートメント検具です。

(Actual performance 1)ENG COMP 検具

ENG COMP 検具
Main function Needs, concerns of customer.
・単品パネルの接合面合わせ込み
【材質】スチール
【Needs, concerns of customer.】
・特に、ENG COMPは厚板部品が多く、加えてR/L差のある部品もあり、検具で合わせ込みが必要。
